◕ Four wheel drive, full power. The whole machine has compact structure and flexible operation. The
structural parts of the whole machine are optimized, stable and reliable.
◕ Reliable battery, drive motor and electrical accessory system, advanced AC controller and CANbus data bus
technology ensure the durability and long endurance of the equipment.
◕ The cover of the whole machine can be turned over to facilitate maintenance. The system maintenance items
are simple and convenient, saving maintenance time and labor cost. Families can charge by themselves, which
is convenient and safe to use.
◕ The operating device is designed by ergonomics, with comfortable operation and stable driving. The whole
machine protection frame provides full safety protection for drivers.
◕ Pure electric system has the advantages of high efficiency, zero exhaust emission, low noise,
environmental protection and energy saving. It is suitable for indoor and outdoor use with lower cost.
◕ A variety of accessories can be selected to meet the needs of various working conditions such as loading,
forking, grass clamping, snow pushing, cleaning, drilling, hoisting and so on.
| Main parameter |
Operating weight |
2450Kg |
| Rated Load |
700Kg |
| Moving speed |
0-18km/h |
| Moving motor |
Motor type |
Permanent magnet synchronous motor |
| Rated power of motor |
20kw |
| Motor Duty Rating |
Duty with non-periodic load and speed variations |
| Hydraulic Pump Moto |
Rated power of motor |
10Kw |
| Motor Duty Rating |
Duty with non-periodic load and speed variations |
| Battery |
Battery Type |
Lithium iron phosphate |
| Battery Voltage |
144V |
| Battery rated capacity |
155Ah(standard) |
| Battery weight |
260Kg |
| Charging time |
AC220V Charge:3h |
| Operating time with full load |
3.5h |
| Operating time with rated load |
4-5h |
| Intermittent operation time |
5-6h |
| Theoretical lifespan |
25 ℃ 0.5c charge and discharge for 3000 times, and the capacity shall not be less than
80% of the nominal capacity
|
| Driving system |
Operating voltage of driving system |
144V |
| Electrical system |
Voltage of electrical system |
12V |
| Tripping load with bucket(Refer to ISO8313) |
Tripping load when straight line driving |
1250Kg |
| Tripping load when full turn |
900Kg |
| Hydraulic drive system |
Displacement |
12 cc |
| Working pressure |
170bar |
| Hydraulic oil capacity |
30L |
| Tyre |
Specifications |
26Í12-12 AS |
| Total width |
1104mm |
A |
Width of protective device |
990mm |
B |
Ground clearance |
178mm |
C |
Tire center width |
803mm |
D |
Total width |
1104mm |
E |
Maximum working height |
3630mm |
F |
Maximum bucket fulcrum height |
2900mm |
G |
Bucket level status height |
2649mm |
H |
Tipping height |
2228mm |
I |
Working distance (tipping state) |
690mm |
J |
Shovel depth |
120mm |
K |
Pivot to bucket lift pin |
550mm |
L |
wheelbase |
1550mm |
M |
Rear overhang |
948mm |
N |
Total length without bucket |
3550mm |
O |
Total length with standard bucket |
4330mm |
Q |
Seat height |
1208mm |
R |
Height to top of protective device |
2290mm |
S |
Angle of maximum lifting height |
48º |
T |
Maximum tipping angle |
45º |
U |
Horizontal position plane corner |
48º |
V |
Departure angle |
24º |
W |
Corner |
45º |
X |
Maximum turning radius |
2530mm |
Y |
Outer edge radius |
2200mm |
Z |
Inner turning radius |
1110mm |
Note:Specifications are subject to changes by the manufacturer without prior notice.
